Print Registration
Initial adjustment (adjustable in increments of T=0.3mm, B-0.5mm, R and L=0.2mm
Left print position accuracy (scanning direction): +/-0.5mm - start on scan
Top print position accuracy (feeding direction): +/-0.5 mm - start on scan
Horizontal page width accuracy: +/-0.5mm - mirror motor
Vertical page length accuracy: +/-0.5mm - drive motor
Print Position Error
Measured at any point in the printable area using core media papers.
Vertical (process): +/-0.7mm
Horizontal (magnification): +/-0.7mm
Duplex Skew Specification
Side: 1 2
Print Sequence Thru Printer: 2nd 1st
16 lb-to-24 lb +/-0.007 mm/mm +/-0.005 mm/mm
All Other Papers +/-0.010 mm/mm +/-0.005 mm/mm
Card Stock +/-0.007 mm/mm +/-0.007 mm/mm
Labels:
- Paper, Dual-Web Paper
- Vinyl, Polyester
(less than or equal 92# liner
+/-0.010 mm/mm
+/-0.010 mm/mm
+/-0.010 mm/mm
+/-0.010 mm/mm
