Repair Information 4-189

4062-XXX

Go Back

SFP stapler assembly sensor (bin full send) removal

1. Remove the stapler/stacker controller card assembly. Go to “Stapler/stacker controller card assembly

removal” on page 4-193.

2. Remove the two screws (A) securing the staple finisher sensor (bin full send).

3. Disconnect the harness and remove.
