Lexmark T650 Series Service Manual

Diagnostic aids 3-101
4062-XXX
Go Back
Previous
Next
3. Raise the recessed duplex bar.
4. Remove the jammed paper,.
5. Replace the duplex jam access tray.
6. Insert the standard tray.
7. Press .
241–245 paper jams
1. Pull out the tray indicated on the display.
2. Remove any jammed paper, and then insert the tray.
3. Press .
4. If the jam message remains for a 250-sheet or 550-sheet tray, then remove the tray from the printer.
5. Remove the jammed paper, and then insert the tray.
6. Press .

Lexmark T650 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 45 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Standard Output Capacity	250 sheets
Processor Speed	500 MHz
Connectivity	USB, Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Memory	128 MB, expandable to 640 MB
Standard Input Capacity	650 sheets
