Diagnostic aids 3-19
4062-XXX
To run the Finisher Sensor Test:
1. Select Sensor Test from FINISHER TESTS.
2. Select one of the four tests to perform:. Each of the tests displays the individual sensors that can be
manually actuated, and the display shows Open or Closed.
• Staple Sensors
Cartridge Present sensor
Staple Low sensor
Self-priming sensor
Home signal sensor
• Cover and Door
Finisher top cover sensor
Side door sensor
• Pass and Media
Finisher pass thru
Media sensor
• Bin Level
Finisher bin empty
Bin full sensor
Bin near full
3. Press Back or Stop to exit the test.
BASE SENSOR TEST
This test is used to determine if the sensors located inside the printer are working correctly.
To run the Base Sensor Test:
1. Select BASE SENSOR TEST from the DIAGNOSTICS menu.
The following sensors are listed:
• Toner Level—Toner level sensor (remove the cartridge and replace to actuate the sensor)
• Input—Input sensor
• Output—Output (exit) sensor
• NarrowMedia—Output (exit) sensor
• Front Door—Front door sensor
2. Manually actuate the sensors to verify that each sensor switches from Open to Closed.
3. Press Back or Stop to exit the test.
PRINTER SETUP
Defaults
US/Non-US defaults changes whether the printer uses the US factory defaults or the non-US factory defaults.
The settings affected include paper size, envelope size, PCL symbol set, code pages, and units of measure.
WARNING: Changing this setting resets the printer to factory defaults, and data may be lost. It cannot be
undone.
Printed Page Count
