is now stuck to the photoconductor (drum) due to the relative electrical differences between the negative
electrical charge of the inner conductive layer of the drum and the positive electrical charge of the paper.
Cleaning
The Cleaning Blade removes any toner that remains on the drum after the transfer process. The toner that the
Cleaning Blade removes is collected inside the sealed PC Cartridge.
Sheet of paper
HVPS
-VDC
-VDC
DRUM
Transfer roll
Cleaning Blade
Used Toner
Charge roll
DRUM

Lexmark T650 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 45 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Standard Output Capacity	250 sheets
Processor Speed	500 MHz
Connectivity	USB, Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Memory	128 MB, expandable to 640 MB
Standard Input Capacity	650 sheets
