Diagnostic information 2-125
4062
Go Back
Previous
Next
Sensor (input) early jam service check
6
Check the sensor (fuser output) for proper operation.
1. Enter the diagnostic mode
2. Select Base sensor test
3. Observe the line item “exit
Caution: The area around the actuator is very hot. Allow the
fuser area to cool before proceeding.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 8. Go to step 7.
7
Check the above sensor for proper connection.
Is the above sensor connected properly?
Replace the fuser
unit assembly.
Go to “Fuser unit
assembly
removal” on
page 4-22.
Replace the
connection.
8
Perform a print test and check the main motor assembly.
Is the media properly transported and able to reach the
sensor (fuser output)?
Replace the main
drive motor
assembly.
Go to “Output
cover assembly
removal” on
page 4-53.
Replace the
connection.
9
Check the aligner assembly for obstructions.
Is the above component free from obstructions?
Go to step 10. Remove
obstructions.
10
Perform a print test.
Does the problem remain?
Contact next
highest level of
tech support.
Problem solved.
Use this procedure for the following jams:
200.04 200.06 200.08 200.14 200.33
Step Check Yes No
1 Check media origination.
Did the media originate from the MPF?
Go to step 2. Go to step 5.
2
Check the MPF pick roll assembly.
Is the above component free of excess wear and
contamination?
Go to step 3. Clean or replace
the MPF pick roll
assembly.
Go to “MPF pick
roll assembly
removal” on
page 4-37.
Step Check Yes No
