Lexmark T650 Series Service Manual

4-164 Service Manual
4062-XXX
Go Back
Previous
Next
Output expander right inner cover removal
1. Remove the output expander right outer cover. Go to “Output expander right outer cover removal” on
page 4-163.
2. Remove the screw (A) securing the right inner cover to the unit.
3. At the rear of the right inner cover, pull out from the option and remove the right inner cover.
Output expander media bin latch (left and right) removal
1. Remove the output expander left or right inner cover. Go to “Output expander left inner cover removal”
on page 4-163 or “Output expander right inner cover removal” on page 4-164.
2. If removing the right side media bin latch, use a springhook to pull the media bin latch spring off the spring
post on the output expander frame.
3. If removing the left side media bin latch, just pull out on the bottom of the latch and pull the top off the boss.
4. Pull the media bin latch from its boss to remove.
A

Lexmark T650 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 45 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Standard Output Capacity	250 sheets
Processor Speed	500 MHz
Connectivity	USB, Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Memory	128 MB, expandable to 640 MB
Standard Input Capacity	650 sheets
