4. Detach the operator panel door assembly from the machine.
5. Remove the black plastic cover.
6. Remove the two screws (C) securing the USB socket to the assembly.
7. Remove the USB socket.
8. Disconnect the connector (D) from the assembly.
Operator panel hinge assembly, left removal (T650, T652, T654)
1. Remove the operator panel door assembly. Go to “Operator panel door assembly removal (T650, T652,
T654)” on page 4-43.
2. Remove the screw (A) securing the cover to the operator panel hinge assembly, left.
3. Remove the cover.
4. Detach the switch (B) from the operator panel hinge assembly, left.
DC

Lexmark T650 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 45 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Standard Output Capacity	250 sheets
Processor Speed	500 MHz
Connectivity	USB, Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Memory	128 MB, expandable to 640 MB
Standard Input Capacity	650 sheets
