Lexmark T650 Series Service Manual

Repair Information 4-99
4062-XXX
Go Back
Previous
Next
5-bin mailbox sensor (deflector gate HP) removal
1. Remove the 5-bin left inner cover. Go to “5-bin mailbox left inner cover removal” on page 4-85.
2. Remove the following harnesses from the controller card: J14 A and B, J2, and J11.
3. Remove the two screws (A) securing the controller card assembly and move the card to the side.
A

Lexmark T650 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 45 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Standard Output Capacity	250 sheets
Processor Speed	500 MHz
Connectivity	USB, Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Memory	128 MB, expandable to 640 MB
Standard Input Capacity	650 sheets
