Lexmark T650 Series - Page 420

4-100 Service Manual
4062-XXX
Go Back
Previous
Next
4. Remove the four screws (B) securing the left frame assembly to the 5-bin mailbox assembly.
5. Move the left frame assembly out of the way.
6. Remove the 5-bin mailbox sensor (deflector gate HP) by pressing the tabs.
B
