SFP stapler assembly top cover removal
1. Remove the left and right cover. Go to “SFP stapler assembly left cover removal” on page 4-174 and
“SFP stapler assembly right cover removal” on page 4-173.
2. Remove the two screws (A) from the left and right side of the top cover.
3. Pull up and toward the front to remove the top cover.
A
