Diagnostic information 2-143
4062
Go Back
Previous
Next
Sensor (output pass through) static jam service check
3
Check the sensor (output pass through) for proper
operation.
1. Enter the diagnostic mode
2. Select Output bin tests
3. Select Sensor test
4. Select Output bin x
5. Observe the line item “passthru
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked.
Go to step 5. Go to step 4.
4
Check the above sensor for proper connection.
Is the above sensor connected properly?
Replace the
sensor (output
pass through).
Go to “High
capacity stacker
sensor (pass
through)
removal” on
page 4-145.
Go to “5-bin
mailbox sensor
(pass through)
removal” on
page 4-90.
Go to “Output
expander sensor
(pass through)
removal” on
page 4-170.
Replace the
connection.
5
Perform a print test using the output option.
Does the error continue?
Replace the output
option.
Problem solved.
Step Check Yes No
1 Check the media path for partially fed or jammed media.
Is the media path free from partially fed or jammed media?
Go to step 2. Remove any pre-
staged or jammed
media.
2
Check the sensor (output pass through) for proper
operation.
1. Enter the diagnostic mode
2. Select Output bin tests
3. Select Sensor test
4. Select Output bin x
5. Observe the line item “passthru”
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked.
Go to step 4. Go to step 3.
Step Check Yes No
