DUPLEX TESTS (if installed)
Quick Test See “Quick Test (duplex)” on page 3-12
Top Margin See “Top Margin (duplex)” on page 3-13
Sensor Test See “Sensor Test (duplex)” on page 3-13
Motor Test See “Motor Test (duplex)” on page 3-14
Duplex Feed 1 See “Duplex Feed 1” on page 3-14
Duplex Feed 2 See “Duplex Feed 2” on page 3-14
INPUT TRAY TESTS
Feed Tests See “Feed Tests (input tray)” on page 3-15
Sensor Test See “Sensor Test (input tray)” on page 3-15
OUTPUT BIN TESTS
Feed Tests See “Feed Tests (output bins)” on page 3-15
Feed To All Bins See “Feed To All Bins” on page 3-16
Sensor Test See “Sensor Test (standard output bin)” on page 3-16
Deflector Test (if 5-bin
installed)
See “Deflector Test” on page 3-18
FINISHER TESTS (if installed)
Staple Test See “Staple Test” on page 3-18
Feed Tests See “Feed Tests (finisher)” on page 3-18
Sensor Test See “Sensor Test (finisher)” on page 3-18
BASE SENSOR TEST See “BASE SENSOR TEST” on page 3-19
Toner See “Toner Level—Toner level sensor (remove the cartridge and
replace to actuate the sensor)” on page 3-19
Input See “Input—Input sensor” on page 3-19
Output See “Output—Output (exit) sensor” on page 3-19
NarrowMedia See “NarrowMedia—Output (exit) sensor” on page 3-19
Front Door See “Front Door—Front door sensor” on page 3-19
PRINTER SETUP
Defaults See “Defaults” on page 3-19
Page Count See “Printed Page Count” on page 3-19
Perm Page Count See “Perm Page Count (permanent page count)” on page 3-20
Serial Number See “Serial Number” on page 3-20
Engine Setting 1 through 4 See “Engine Setting 1 through 16” on page 3-20
Model Name See “Model Name” on page 3-20
Configuration ID See “Configuration ID” on page 3-20
Edge to Edge See “Edge to Edge” on page 3-21
