2. Remove the six screws (A) securing the metal cover to the machine.
3. Remove the metal cover.
4. Remove the inner deflector. Go to “Inner deflector removal” on page 4-24.
5. Remove the MPF pick solenoid assembly. Go to “MPF pick solenoid assembly removal” on page 4-38.
A
