Repair Information 4-25
4062-XXX
Go Back
Previous
Next
2. Release the two hooks (A) securing the lower portion of the inner deflector to the machine.
3. Remove the inner deflector.
Replacement Warning: When replacing the inner deflector, ensure that it is properly installed, or jamming will
occur.
A
