6. Remove eight screws (E) securing the scanner controller cage cover to the cage. An X658 model is
represented in the graphic below, however, the card cage cover removal procedure is similar for all
models.
7. Remove the printer controller card cage cover.
8. Disconnect the USB cable and the cover closed interlock switch harness.
E
E

Lexmark T650 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 45 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Standard Output Capacity	250 sheets
Processor Speed	500 MHz
Connectivity	USB, Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Memory	128 MB, expandable to 640 MB
Standard Input Capacity	650 sheets
