Repair Information 4-65
4062-XXX
Go Back
Previous
Next
3. Remove the cover assembly, rear lower. Go to “Cover assembly, rear lower removal (T650)” on
page 4-12.
4. Remove the four screws (A) securing the side cover, left to the machine.
5. Swing the side cover, left away from the machine.
6. Remove the side cover, left.
A
A
