4. Remove the screw (A) securing the appropriate 5-bin mailbox deflector gate solenoid.
5. Remove and unroute the cable to the deflector gate solenoid.
6. Disconnect the proper deflector gate solenoid harness from the controller card.
Note: To ease the cable unrouting, cut the appropriate cable.
A

Lexmark T650 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 45 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Standard Output Capacity	250 sheets
Processor Speed	500 MHz
Connectivity	USB, Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Memory	128 MB, expandable to 640 MB
Standard Input Capacity	650 sheets
