Lexmark T650 Series Service Manual

Parts catalog 7-13
4062-XXX
Go Back
Previous
Next
Assembly 6: Printhead, charge, and transfer
Asm-
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X4464 1 2 Printhead with cable assembly (T652 and T654)
1 40X7040 1 1 Printhead with cable assembly (T656)
2 40X1865 1 1 Printhead cable (T652, T654, and T656)
3 40X4463 1 2 Printhead with cable assembly (T650)
4 40X4367 1 1 Printhead cable assembly (T650)
5 40X4317 1 1 Charge roll link spring, right
6 40X1893 1 4 Charge roll arm assembly with cable, right
7 40X1888 1 2 Transfer roll bracket assembly, right
8 40X1886 1 1 Transfer roll assembly with tool
9 40X1887 1 2 Transfer roll bracket with cable assembly, left
10 40X0127 1 1 Charge roll assembly with tool
11 40X1892 1 4 Charge roll arm assembly, left
12 40X4316 1 1 Charge roll link spring, left
13 40X1864 1 1‘ Print cartridge ID connector assembly
14 40X4363 1 1 Main cooling fan (T650)
14 40X4364 1 1 Main cooling fan (T652, T654, and T656)
15 40X4372 1 1 Sensor (standard bin exit) actuator assembly
16 40X4369 1 1 Sensor (standard bin exit)

Lexmark T650 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 45 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Standard Output Capacity	250 sheets
Processor Speed	500 MHz
Connectivity	USB, Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Memory	128 MB, expandable to 640 MB
Standard Input Capacity	650 sheets
