Lexmark T650 Series Service Manual

Parts catalog 7-15
4062-XXX
Go Back
Previous
Next
Assembly 7: Pick arm assembly, trays, and MPF
Asm-
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X4394 1 1 Tray catch spring
2 40X4395 1 1 Tray roller catch assembly
3 40X6994 1 1 MPF pick solenoid assembly
4 40X4457 1 1 MPF cam gear
5 40X1883 4 1 MPF pick roll assembly with flanges and clip
6 40X4458 1 1 MPF lift plate assembly (T650)
6 40X4459 1 1 MPF lift plate assembly (T652, T654, and T656)
7 40X4460 1 1 MPF tray door assembly (T650)
7 40X4461 1 1 MPF tray door assembly (T652)
7 40X1884 1 1 MPF tray door assembly (T654)
8 40X4313 1 1 Pick arm sensor cable assembly
9 40X4304 1 1 Pick arm assembly with spring, 250 sheet (T650)
9 40X4305 1 1 Pick arm assembly with spring, 500 sheet (T652, T654, and T656)
10 40X4306 1 1 Pick arm spring (T650)
11 40X4308 1 2 Pick roll assembly (2)
12 40X1384 1 1 250 Sheet media out actuator (T650)
13 40X6391 1 1 Media tray assembly, 250 sheet
13 40X5786 1 1 Media tray assembly, 550 sheet
14 40X6932 3 1 Trays size sensing actuator
15 40X4472 1 1 Switch (media size) assembly
16 40X4307 1 1 Pick arm spring (T652, T654, and T656)
17 40X4310 1 1 550 Sheet media out actuator (T652, T654, and T656)
18 40X1876 1 1 MPF gear shield

Lexmark T650 Series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 45 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Standard Output Capacity	250 sheets
Processor Speed	500 MHz
Connectivity	USB, Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS, Linux
Memory	128 MB, expandable to 640 MB
Standard Input Capacity	650 sheets
