Lexmark T650 Series Service Manual

Parts catalog 7-23
4062-XXX
Go Back
Previous
Next
Assembly 11: 550 Sheet option tray assembly
Asm-
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X4576 1 1 Complete 550 sheet option tray assembly
2 40X3454 1 1 550 Sheet pick arm bracket assembly
3 40X4307 1 1 550 Sheet bellcrank recoil spring
4 40X4308 1 2 Pick roll assembly (2)
5 40X4369 1 1 Sensor (media low)
6 40X4369 1 1 Sensor (media empty)
7 40X4310 1 1 550 Sheet media out actuator
8 40X4570 2 2 Anti-tip latch assembly
9 40X3957 1 1 550 Sheet option drawer assembly
10 40X3822 1 1 Media tray catch spring
11 40X4395 1 1 Media tray roller catch assembly
12 40X4469 1 1 Media tray assembly, 550 sheet
13 40X6932 3 1 Tray size sensing actuator
14 40X4575 1 1 Sensor (pass through) with cable
15 99A0447 1 1 550 Option drive shaft
16 99A0275 1 1 Spring
17 40X4572 1 1 Lower interface cable assembly
18 40X3854 1 1 Media size actuator
19 40X4578 1 1 550 Sheet controller card assembly
20 40X4571 1 1 Upper interface cable assembly
