Note: The SM connectivity provisioning does not apply to
DRM/VCDX.
The flowchart indicates that some steps can be executed
synchronously and asynchronously. Below is an acceptable sequence
of the steps displayed in Figure 5-1, “SM Connectivity Provisioning
Flowchart” (5-3) .
1. “Feature Activation (RC/V 8.22)” (5-13)
2. “Insert SIP Global SM (RC/V 5.80)” (5-16)
3. “Define Protocol Handler (RC/V 22.4)” (5-18)
4. “PH Channel Group Assignment (RC/V 22.16)” (5-19)
5. “ Assign QPH Pipe (RC/V 17.24)” (5-23)
6. “Assign MH Pipe (RC/V 17.20)” (5-26)
7. “Update GSM - Non-GSM Communication (RC/V 17.27)” (5-28)
8. “Insert Call Processing SM (RC/V 5.81)” (5-31)
Figure 5-1 SM Connectivity Provisioning Flowchart
SECURED FEATURE
(RC/V 8.22)
UPGRADE
SIP GSM
(RC/V 5.80)
SIP CALL
(RC/V 5.81)
PROCESSING SMS
QPH
(RC/V 17.27)
CONNECTIVITY
QPH PIPE
(RC/V 17.24)
ASSIGNMENT
MH PIPE
(RC/V 17.20)
ASSIGNMENT
EQUIPMENT SUBUNIT -
(RC/V 22.4)
PROTOCOL HANDLER
PSU PROTOCOL
(RC/V 22.16)
HANDLER CHANNEL
GROUP ASSIGNMENTS
Provisioning Sequences
Provisioning
....................................................................................................................................................................................................................................
235-200-118
Issue 3.02B, March 2007
Lucent Technologies
5-3
