Procedure
............................................................................................................................................................
1
Select and prepare terminal for RC/V activities.
Reference:
“Select and Prepare Terminal” (5-11)
............................................................................................................................................................
2
Type and enter the RC/V form number.
5.83
Result:
Enter Database Operation I=Insert,R=Review,U=Update,
D=Delete:
............................................................................................................................................................
3
Type and enter the insert command.
I
Result:
The SIP PSTN INTERWORKING PARAMETER SET page is
displayed and the cursor is located at the SET NAME field.
............................................................................................................................................................
4
Type and enter the *SET NAME field value.
............................................................................................................................................................
5
Using the RC/V 5.83 form as a guide, modify the parameters if
necessary.
The fields listed below appear on Screen 1 and are the SIP TO PSTN
MAPPING RULES.
• CALLING PARTY INFO
• CALLED PARTY NUMBER
• TRANSIT NETWORK SELECTION
• REDIRECTING INFO
• ORIGINATING LINE INFO
• HOP COUNTER
• CARRIER SELECTION
The fields listed below appear on Screen 2 and are the PSTN TO SIP
MAPPING RULES.
• REQUEST URI ADDR
• REQUEST URI CIC
Insert SIP PSTN Interworking Parameter Set
(RC/V 5.83)
Provisioning
....................................................................................................................................................................................................................................
235-200-118
Issue 3.02B, March 2007
Lucent Technologies
5-75
