214323 150 Revision B
Figure 4.38: Case Combine Console
8. If you need to change the position of one of the presets,
you can fine-tune this setting with button (A) on the
combine console.
Figure 4.39: Float Indicator Box
NOTE:
In most cases, the ideal ground pressure is one number (on
float indicator box) above the setting at which the header
is suspended off the ground. For example, if the float
indicator pointer is positioned at 0 (B) with the header
suspended off the ground, then the ideal ground pressure
will be achieved with the pointer positioned at 1 (A).
Operating the header with heavier pressures can wear out
the cutterbar wearplate quickly.
AUTO HEADER HEIGHT CONTROL
