MacDon FlexDraper FD75 - Setting Cutting Height - CLAAS 500 Series

214323 180 Revision B
1003744
A
B
Figure 4.105: Joystick Buttons
NOTE:
The reel fore-aft position can also be set using the joystick.
9. Press and hold button (A) or button (B) for 3 seconds to
store the setting in the CEBIS. An alert sounds when the
new setting has been stored.
NOTE:
Whenever button (A) or button (B) is pressed for 3 seconds,
the current positions for the reel speed and the cutting
height are saved.
AUTO HEADER HEIGHT CONTROL
