214323 303 Revision B
1001495
A
Figure 5.32: Driveline
4. Disconnect the driveline from combine output shaft (A).
1001452
B
A
Figure 5.33: Driveline
5. Slide the driveline into hook (A) until disc (B) drops.
1001496
A
B
C
Figure 5.34: Multicoupler
6. Disconnect the harness from connector (A).
7. Move handle (B) on the combine multicoupler to the full
open position to release multicoupler (C) from the
combine.
HEADER ATTACHMENT/DETACHMENT
