MacDon FlexDraper FD75 - Page 326

214323 308 Revision B
1001470
A
Figure 5.44: Driveline
12. Rotate disc (A) on the adapter driveline storage hook, and
remove the driveline from the hook.
1001412
B
A
Figure 5.45: Driveline
13. Pull back collar (A) on end of the driveline, and push the
driveline onto combine output shaft (B) until the
collar locks.
HEADER ATTACHMENT/DETACHMENT
