214323 320 Revision B
Figure 5.73: Adapter Pin
13. Reinsert locking pin (C) to secure adapter pin (B).
Figure 5.74: Header on Combine
14. Lower the feeder house until feeder house posts (A)
disengage from adapter (B).
15. Back the combine away slowly from the adapter.
HEADER ATTACHMENT/DETACHMENT
