Figure 6.7: Every 50 Hours – Upper Cross Auger
A- Right End Bearing B - Upper Cross Auger U-joints [Two places, accessible by opening cover (D)]
C - Upper Cross Auger Sliding Hubs [Two places, accessible by opening cover (D)] E - Upper Cross Auger Center Bearings (Two Places)
