214323 353 Revision B
Figure 6.8: Every 50 Hours – Upper Cross Auger, Old Assembly
A - Upper Cross Auger U-joint
38
B - Upper Cross Auger Bearing (2 Places)
C - Right End Bearing
MAINTENANCE AND SERVICING
38. The U-joint has a cross and bearing kit with an extended lubrication interval. Stop greasing when greasing becomes
difficult or if the U-joint stops taking grease. Overgreasing will damage the U-joint. Six to eight pumps are sufficient at
first grease (factory). Grease more often as the U-joint wears and requires more than six pumps.
