MacDon FlexDraper FD75 - Page 376

214323 358 Revision B
Figure 6.13: Every 250 Hours
1010519
A
A - Double Reel U-Joint
40
MAINTENANCE AND SERVICING
40. U-joint has an extended lubrication cross and bearing kit. Stop greasing when greasing becomes difficult or if U-joint
stops taking grease. Overgreasing will damage U-joint. Six to eight pumps are sufficient at first grease (factory). Grease
more often as the U-joint wears and requires more than six pumps.
