214323 24 Revision B
Table 2.1 Header Specifications (continued)
Conveyor (Draper) and Decks
Draper width
1057 mm (41.61 in.)
S
Draper drive Hydraulic
S
Draper speed: CA25 Combine Adapter-controlled
141 m/min. (0–464 fpm)
S
Delivery opening width
1870 mm (73.62 in.)
S
PR15 Pick-Up Reel
Quantity of tine tubes
5-, 6-, or 9
Center tube diameter
203 mm (8 in.)
S
Finger tip radius
Factory-set
800 mm (31.5 in.)
S
Finger tip radius Adjustment range
766–800 mm
(30.18–31.5 in.)
S
Effective reel diameter
1650 mm (65 in.)
S
Finger length
290 mm (11 in.)
S
Finger spacing (staggered on alternate bats) 150 mm (6 in.)
S
Reel drive Hydraulic
S
Reel speed (adjustable from cab, varies with combine model)
0–67 rpm S
Frame and Structure
Header
width
Field mode
Cut width +
384 mm (15.12 in.)
S
Header
width
Transport position—reel
fore-aft fully retracted
(shortest center-link)
(A)
2
,
3
(B)
2
,
4
2684 mm (106 in.)
2500 mm (98 in.)
—
PRODUCT OVERVIEW
2. Refer to Figure 2.1, page 25
3. Long dividers removed
4. Long dividers installed
