Table 2.2 Header Attachments
CA25 Combine Adapter
S
Feed draper
Width
2000 mm (78.7 in.)
S
Feed draper Speed
107–122 m/min
(350–400 fpm)
S
Feed auger
Width
1660 mm (65.3 in.)
S
Feed auger
Outside diameter
559 mm (22 in.)
S
Feed auger
Tube diameter
356 mm (14 in.)
S
Feed auger
Speed (varies with
combine model)
150 rpm
S
Oil reservoir capacity
(60 liters)
16 US gallons
S
Oil type
15W40
—
Driveline overall
length
5
Case, New Holland
Maximum (extended) 1230 mm (48.4 in.)
O
F
Driveline overall
length
5
Case, New Holland
Minimum (compressed)
970 mm (38.2 in.)
O
F
Driveline overall
length
5
Challenger, Gleaner, John
Deere, CLAAS,
Massey Ferguson
Maximum (extended) 1262 mm (49.7 in.)
O
F
Driveline overall
length
5
Challenger, Gleaner, John
Deere, CLAAS,
Massey Ferguson
Minimum (compressed)
916 mm (36.1 in.)
O
F
Upper Cross Auger
O
D
Flighting (outside diameter [O.D])
305 mm (12 in.)
—
Tube diameter (O.D)
All header sizes except 7.6
m (25 ft.)
152 mm (6 in.) —
Tube diameter (O.D) 7.6 m (25 ft.) headers 178 mm (7 in.)
—
Stabilizer Wheel / Slow Speed Transport
O
D
Wheels diameter
381 mm (15 in.) —
Tires
P205/75 R-15
—
Weight
6
9.1 m (30 ft.) header 3060–3162 kg (6746–6971 lb.)
10.7 m (35 ft.) header 3251–3370 kg (7167–7430 lb.)
12.2 m (40 ft.) header
North America frame
3442–3533 kg (7589–7789 lb.)
12.2 m (40 ft.) header
Export frame
3549 kg (7824 lb.)
13.7 m (45 ft.) header
North America frame
3728 kg (8218 lb.)
13.7 m (45 ft.) header
Export frame
3744 kg (8253 lb.)
PRODUCT OVERVIEW
5. Subtract 265 mm (10-7/16 in.) for the length between the yoke pins.
6. Estimated weight range with base header only (variances are due to different package configurations).
