Model and Serial Number
Record the model number, serial number, and model year of the header, combine adapter, and transport/stabilizer wheel
option (if installed) in the spaces provided.
NOTE:
Right and left designations are determined from the operator’s position, facing forward.
1022661
A
Figure 1: Header
Draper Header
Header Model:
Serial Number:
Year:
The serial number plate (A) is located in the lower corner on
the left endsheet.
1022663
A
Figure 2: Adapter
Combine Adapter
Adapter Model:
Serial Number:
Year:
The serial number plate (A) is located on the underside of the
reservoir at the left end.
1005072
A
Figure 3: Transport/Stabilizer Option
Slow Speed Transport/Stabilizer Wheel Option
Serial Number:
Year:
The serial number plate (A) is located on the right axle
assembly.
