MacDon FlexDraper FD75 - Page 98

214323 80 Revision B
1023950
A
B
Figure 3.84: Gleaner Controls
1024013
A
B
Figure 3.85: Challenger
®
/Massey Ferguson
®
Controls
CLAAS combines:
CLAAS (with Dealer-installed fore-aft / header tilt switch): Some CLAAS combines use a combination of the reel fore-aft
switches on the control handle and a Dealer-installed auxiliary rocker switch which toggles between reel fore-aft and
header tilt functionality.
OPERATION
