IMPORTANT:

At the beginning, the slide rail assemblies are assembled so that they are

suited for the rack with square holes. Before mounting to the rack with round

holes, swap two brackets of the front and rear side.

フロント側

リヤ側

フロント側

リヤ側

フロント側へ

リヤ側へ

Front Side

Rear Side

swap
