Hardware
147
This completes mounting the server to the rack.
When mounting cable with the bracket, refer the figures below.
Fix the parts in reverse
Front side
Fix the parts in reverse
Front side
NOTE:
It is possible to mount the brackets in reverse so that it is fit to
long length of rack.
Support bracket 1 (Cable arm side)
Support bracket 2 (Cable cover side)
