Hardware
146
28. Adjust the support bracket corresponding to the rack length.
As far as possible
NOTE:
There are many holes on the support bracket so that it is
ad
j
ustable to be fit to the rack.
[1]Fix the arm at the place where the system can be pulled out from the rack completely.
[2]make sure not to hit each other when the arm is closed.
5
–
40mm depending on the rack size
