Operation and Maintenance
619
EFI Manager Booted EFI Manager Booted status
OS or T&D Starting OS or T&D Starting status
T&D Running T&D Running status
OS Running OS Running status
Stopping Shutting down (loading) status
Handling Fault Handling Fault status
Handling DP Handling DP status
* The following describes the relationship between status of System Health and Server Health, and
the suspected failure.
System Server 1 Server 2 Main Console to
Check Log, etc
Possible Failure
Normal -(Normal) -(Normal) - Normal
Normal System Failure outside the
server
Normal
Other than
Normal
Server2 Failure within Server 2
(Only A1080a-D)
Normal Server1 Failure within Server 1
Health
Other than
Normal
Other than
Normal
Other than
Normal
Server1 and
Server2
Common failure on
Server 1 and Server 2,
or each server failure.
(Only A1080a-D)
(4) Power Consumption by BaseModule: Status of Resource (BM)
Resource : BaseModule (BM) name
Display Value Description
Base Module1 On Server1 side
Base Module2 On Server2 side
Base Module Com1/2 Common parts (FAN, LCD, DVD, USB)
Power : DC power status of the BM
Display Value Description
Off DC power of the relevant server is OFF.
On DC power of the relevant server is ON.
Wattage : Power consumption
Health : Operating status of the BM
Display Value Description
Normal No failure occurred, or only correctable error
occurred.
Non-Critical Recoverable Error occurred. Maintenance of the
Server is required.
Critical Fatal Error has occurred; maintenance of the
Server is required.
