Default Settings
309978-D Rev 01 G-5
Note: The following two fields only appear when a single Phy
MDA with a separate redundant Phy port is installed.
Preferred Phy Right
Active Phy Read-only field indicating the
operational Phy port (Right,
Left, or None)
MultiLink Trunk Configuration
(
page 3-64)
Trunk Members (Unit/Port) Zero-length string
STP Learning Normal
Trunk Mode Basic
Trunk Status Enabled
Trunk Name Trunk #1 to Trunk #6
MultiLink Trunk Utilization (page 3-68) Traffic Type Rx and Tx
Port Mirroring Configuration (page 3-71) Monitoring Mode Disabled
Monitor/Unit Port Zero-length string
Unit/Port X Zero-length string
Unit/Port Y Zero-length string
Address A 00-00-00-00-00-00
(no MAC address assigned)
Address B 00-00-00-00-00-00
(no MAC address assigned)
Rate Limiting Configuration (page 3-75) Packet Type Both
Limit None
IGMP Configuration (page 3-79) VLAN 1
Snooping Enabled
Proxy Enabled
Robust Value 2
Query Time 125 seconds
Set Router Ports Version 1
Static Router Ports - (for all ports)
Multicast Group Membership (page 3-83) VLAN 1
(continued)
Table G-1. Factory Default Settings for the BayStack 450 Switch (continued)
CI screen Field Default setting
