RADWAG PUE 7.1 User Manual

277
44. TECHNICAL PARAMETERS
PUE 7.1 PUE 7.1P
Housing plastic panel – stainless steel
IP rating IP43
Installation within
board – IP66/67,
whole unit – IP32
Display TFT 640x480 5,7” with touch screen
Power supply 10 – 28VDC/21W
Operating temperature -10°C ÷ 40°C
OIML III
Verification units quantity 6000
Max input signal 19,5mV
Max voltage per verification unit 3,25µV
Min voltage per verification unit 0,4µV
Min impedance of load cell 50 Ω
Max impedance of load cell 1200 Ω
Power supply for a load cell 5V
Load cells connection 4 or 6 wires + Screen
Weighing platforms quantity Max. 2
2xRS232 Standard
2xUSB Standard
Ethernet Standard
4WE/4WY Standard
Wi-Fi 2,4GHz b,g,n Standard NONE
Multi-range option YES
Outputs parameters
Outputs quantity 4
Outputs type Solid-state relay
Polarization two-way
Type of power supply AC or DC
Maximum switching current 500mA
Maximum voltage 30V
