61
Min threshold signalling colour
Colour selection for signalling MIN
threshold. 18 colours palette available.
OK threshold signalling colour
Colour selection for signalling OK
threshold. 18 colours palette available.
Max threshold signalling colour
Colour selection for signalling MAX
threshold. 18 colours palette available.
Means of operation:
Bar graph home screen contains workspace which background can visualize
MIN, MAX thresholds if they are declared:
• Visualisation of mass value lower than MIN value:
• Visualisation of mass value higher than MIN value and lower than MAX
value:
• Visualisation of mass value higher than MAX value:
