R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
1186User Manual 1173.9411.02 ─ 43
Example:
CALC:MARK:FUNC:NOIS ON
Switches on the noise measurement.
Manual operation: See "Noise Measurement State" on page 536
See "Switching All Noise Measurement Off" on page 536
14.8.3.10 Phase Noise Measurement Marker
The following commands control the phase noise measurement marker function.
Useful commands for phase noise markers described elsewhere
●
CALCulate<n>:DELTamarker<m>:FUNCtion:FIXed:RPOint:MAXimum[:
PEAK]
●
CALCulate<n>:DELTamarker<m>:FUNCtion:FIXed:RPOint:X
●
CALCulate<n>:DELTamarker<m>:FUNCtion:FIXed:RPOint:Y
Remote commands exclusive to phase noise markers
CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise:AUTO............................................. 1186
CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise:RESult?.......................................... 1186
CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise[:STATe]........................................... 1187
CALCulate<n>:MARKer<m>:FUNCtion:PNOise:AOFF.....................................................1188
CALCulate<n>:MARKer<m>:FUNCtion:PNOise:RESult?..................................................1188
CALCulate<n>:MARKer<m>:FUNCtion:PNOise[:STATe]...................................................1188
CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise:AUTO <State>
This command turns an automatic peak search for the fixed reference marker at the
end of a sweep on and off.
Suffix:
<n>
.
Window
<m> Marker
Parameters:
<State> ON | OFF | 0 | 1
OFF | 0
Switches the function off
ON | 1
Switches the function on
Example:
CALC:DELT:FUNC:PNO:AUTO ON
Activates an automatic peak search for the reference marker in
a phase-noise measurement.
Manual operation: See "Defining Reference Point" on page 539
CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise:RESult?
This command queries the result of a phase noise measurement.
Analyzing Measurements (Basics)
