Remote Commands
R&S
®
FSW
1211User Manual 1173.9411.02 ─ 43
<dl> 1 to 4
time line
Parameters:
<Time> Note that you can not set a time line to a position that is higher
than the current sweep time.
Range: 0 s to 1600 s
*RST: (STATe to OFF)
Default unit: S
Example:
CALC:TLIN 10ms
Sets the first time line to 10 ms.
Manual operation: See "Vertical Line <x>" on page 558
CALCulate<n>:TLINe<dl>:STATe <State>
This command turns a time line on and off
Suffix:
<n>
.
Window
<dl> 1 to 4
time line
Parameters:
<State> ON | OFF | 0 | 1
OFF | 0
Switches the function off
ON | 1
Switches the function on
Example:
CALC:TLIN:STAT ON
Turns the first time line on.
14.8.4.2 Defining Limit Checks
Note that in remote control, upper and lower limit lines are configured using separate
commands. Thus, you must decide in advance which you want to configure. The x-val-
ues for both upper and lower limit lines are defined as a common control line. This con-
trol line is the reference for the y-values for both upper and lower limit lines.
● Configuring Limit Lines........................................................................................1211
● Managing Limit Lines.......................................................................................... 1221
● Checking the Results of a Limit Check............................................................... 1224
● Programming Example: Using Limit Lines.......................................................... 1225
Configuring Limit Lines
CALCulate<n>:LIMit<li>:COMMent................................................................................ 1212
CALCulate<n>:LIMit<li>:CONTrol[:DATA]....................................................................... 1212
CALCulate<n>:LIMit<li>:CONTrol:DOMain......................................................................1213
CALCulate<n>:LIMit<li>:CONTrol:MODE........................................................................1213
