R&S FSW Series User Manual

Data Management
R&S
®
FSW
649User Manual 1173.9411.02 ─ 43
Two different printout devices can be configured, for example one for printing and one
for storage to a file. When you execute the "Print immediately" function, the selected
printing device and its settings determine the behavior of the R&S FSW.
Orientation
Selects the page orientation of the printout: portrait or landscape.
Remote command:
HCOPy:PAGE:ORIentation<1|2> on page 1249
Windows Per Page
Defines how many windows are displayed on a single page of the printout. This setting
is only available if Print Multiple Windows is active (see Chapter 11.5.1.1, "Print Con-
tent Settings", on page 640).
If more than one window is printed on one page, each window is printed in equal size.
Remote command:
HCOPy:PAGE:WINDow<1|2>:COUNt on page 1250
Scaling
Determines the scaling of the windows in the printout if Print Multiple Windows is active
(see Chapter 11.5.1.1, "Print Content Settings", on page 640).
If more than one window is printed on one page (see Windows Per Page), each win-
dow is printed in equal size.
"Maintain
aspect ratio"
Each window is printed as large as possible while maintaining the
aspect ratio of the original display.
"Size to fit"
Each window is scaled to fit the page size optimally, not regarding the
aspect ratio of the original display.
Remote command:
HCOPy:PAGE:WINDow<1|2>:SCALe on page 1251
Margins
Defines margins for the printout page on which no elements are printed. The margins
are defined according to the selected unit.
Remote command:
HCOPy:PAGE:MARGin<1|2>:BOTTom on page 1248
HCOPy:PAGE:MARGin<1|2>:LEFT on page 1248
HCOPy:PAGE:MARGin<1|2>:RIGHt on page 1248
HCOPy:PAGE:MARGin<1|2>:TOP on page 1249
HCOPy:PAGE:MARGin<1|2>:UNIT on page 1249
11.5.1.5 Print Color Settings
Access: "Print" > "Print Config" > "Color" tab
Creating Screenshots of Current Measurement Results and Settings
