General Instrument Setup
R&S
®
FSW
695User Manual 1173.9411.02 ─ 43
Remote command:
[SENSe:]CORRection:FRESponse<si>:USER:SLISt<sli>:REMove
on page 1284
[SENSe:]CORRection:FRESponse<si>:USER:SLISt<sli>:CLEar
on page 1280
Move File Up or Down
Moves the selected Touchstone file one position up or down in the list of files, changing
the order in which the correction data is applied.
Remote command:
[SENSe:]CORRection:FRESponse<si>:USER:SLISt<sli>:MOVE on page 1282
Frequency Response active
Activates or deactivates the use of additional frequency response (.fres) files. The
correction data is these files is applied after any correction settings in active Touch-
stone files. Only active files are included in filter calculation.
Remote command:
[SENSe:]CORRection:FRESponse<si>:USER:FSTate on page 1278
Frequency Response File Information
Provides information on loaded frequency response files and the order of their applica-
tion.
ID ← Frequency Response File Information
Consecutive number which determines the order in which the correction files are
applied to the measurement data. The maximum number of files per configuration is
15.
An LED-like symbol indicates whether the file and frequency response in general is
active (symbol "lights up") or not (symbol is dark). A green symbol represents a fre-
quency response (.fres) file.
Filename ← Frequency Response File Information
Name of a loaded Touchstone file.
Magnitude ← Frequency Response File Information
Activates or deactivates the use of the correction data in the selected file for magnitude
results.
Remote command:
[SENSe:]CORRection:FRESponse<si>:USER:FLISt<fli>:MAGNitude[:
STATe] on page 1275
Phase ← Frequency Response File Information
Activates or deactivates the use of the correction data in the selected file for phase
results.
Remote command:
[SENSe:]CORRection:FRESponse<si>:USER:FLISt<fli>:PHASe[:STATe]
on page 1276
Frequency Response Correction (R&S
FSW-K544)
