Renesas RL78/G10 User Manual

RL78/G10 CHAPTER 5 CLOCK GENERATOR
R01UH0384EJ0311 Rev. 3.11 101
Dec 22, 2016
(1) X1 oscillation:
As of December, 2013
Manufacturer Resonator Part Number
SMD/
Lead
Frequency
(MHz)
Recommended Circuit Constants
Note 1
(reference)
Oscillation Voltage
Range (V)
C1 (pF) C2 (pF) Rd (kΩ) MIN. MAX.
Murata
Manufacturing
Co., Ltd.
Note 2
Crystal
resonator
CSTCC2M00G56-R0 SMD 2.0 (47) (47) 0
1.6 5.5
CSTCR4M00G55-R0 SMD 4.0 (39) (39) 0
CSTLS4M00G53-B0 Lead (15) (15) 0
CSTCE8M00G52-R0 SMD 8.0 (10) (10) 0
CSTLS8M00G53-B0 Lead (15) (15) 0
CSTCE16M0V53-R0 SMD
16
(15) (15) 0
CSTLS16M0X51-B0 Lead (5) (5) 0
CSTCE20M0V51-R0 SMD
20
(5) (5) 0
CSTCE8M00G52-R0 SMD 8.0 (10) (10) 0
1.8 5.5
CSTCE16M0V53-R0 SMD
16.0
(15) (15) 0
CSTLS16M0X51-B0 Lead (5) (5) 0
CSTCE20M0V51-R0 SMD
20.0
(5) (5) 0
Kyocera
Crystal Device
Co., Ltd.
Note 3
Crystal
resonator
CX8045GB
SMD 4.0 10 10 0 2.5 5.5
CX5032SA
SMD 8.0 9 9 0
CX3225SB
SMD 12.0 9 9 0
CX2016DB
SMD 20.0 4 4 0
Notes 1. Values in parentheses in the C1 and C2 columns indicate an internal capacitance.
2. When using this resonator, for details about the matching, contact Murata Manufacturing Co., Ltd.
(http://www.murata.com).
3. When using this resonator, for details about the matching, contact Kyocera Crystal Device Co., Ltd.
(http://www.kyocera-crystal.jp/eng/index.html, http://global.kyocera.com).
