RL78/G10 CHAPTER 6 TIMER ARRAY UNIT

R01UH0384EJ0311 Rev. 3.11 103

Dec 22, 2016

For details about each function, see the table below.

Independent channel operation function Simultaneous channel operation function

• Interval timer (→ refer to 6.8.1)

• Square wave output (→ refer to 6.8.1)

• External event counter (→ refer to 6.8.2)

• Divider function

Note 2

(→ refer to 6.8.3)

• Input pulse interval measurement (→ refer to 6.8.4)

• Measurement of high-/low-level width of input signal

(→ refer to 6.8.5)

• Delay counter (→ refer to 6.8.6)

• One-shot pulse output (→ refer to 6.9.1)

• Two-channel input with one-shot pulse output function

Note

(→ refer to 6.9.2)

• PWM output function (→ refer to 6.9.3)

• Multiple PWM output function

Note 1

(→ refer to 6.9.4)

It is possible to use the 16-bit timer of channels 1 and 3 as two 8-bit timers (higher and lower). The functions that can

use channels 1 and 3 as 8-bit timers are as follows:

• Interval timer (higher and lower 8-bit timers)

• Square wave output (lower 8-bit timer only)

• External event counter (lower 8-bit timer only)

• Delay counter (lower 8-bit timer only)

• PWM output function (lower 8-bit timer only)

• Multiple PWM output function

Note 1

(lower 8-bit timer only)

Interlinked operation of channel 1 with the serial array unit operating as UART0 can be obtained by setting the ISC

party in communications and make the required adjustments in response.

Notes 1. 16-pin products only.

2. Only channels 0 and 3
