Notes 1. In one-count mode, the interrupt request signal (INTTM0n) when starting a count operation and
TO0n output are not controlled.
2. If the start trigger (TS0n = 1) is issued during operation, the counter is initialized, and recounting is
started (interrupt request signal (INTTM0n) is not generated).
Caution Be sure to clear bits 4 and 5 in registers TMR00L to TMR03L to 0.
Remark n: Channel number
n = 0, 1 (for 10-pin products); n = 0 to 3 (for 16-pin products)
