RL78/G10 CHAPTER 6 TIMER ARRAY UNIT

R01UH0384EJ0311 Rev. 3.11 158

Dec 22, 2016

Figure 6-40. Block Diagram of Operation as Interval Timer/Square Wave Output

CK00

CK01

TS0n

Timer counter

TO0n pin

Interrupt signal

(INTTM0n)

Timer data

Interrupt

controller

Output

controller

Clock selection

Trigger selection

Operation clock

Figure 6-41. Example of Basic Timing of Operation as Interval Timer/Square Wave Output (MD0n0 = 1)

TS0n

TE0n

TDR0n

TCR0n

TO0n

INTTM0n

a+1

0000H

a+1

b+1

b+1 b+1

Remarks 1. n: Channel number

n = 0, 1 (for 10-pin products); n = 0 to 3 (for 16-pin products)

2. TS0n: Bit n of timer channel start register 0 (TS0)

TE0n: Bit n of timer channel enable status register 0 (TE0)

TCR0n: Timer count register 0n (TCR0n)

TDR0n: Timer data register 0n (TDR0n)

TO0n: TO0n pin output signal
